Round Roll Lifter PF4120R/PF4150R
The round roll lifter is designed for handling roll and coil materials in warehouses, workshops, packaging areas, and production lines. The catalog presents manual hydraulic and semi-electric options, giving buyers a choice between simple foot-pump lifting and powered lifting assistance for more frequent roll transportation.
This product is suitable when roll materials need to be lifted, positioned, or moved without using a forklift. Roller contact helps support cylindrical goods during handling.
Key Features
- Manual hydraulic model uses a hydraulic pump and heavy-duty lifting chains installed in the middle section.
- Manual lifting is driven by hand crank or foot pedal hydraulic pump.
- Lowering is achieved through hydraulic pressure relief.
- Semi-electric model uses a lithium battery control box and side-mounted motor.
- Electric button lifting with hydraulic assistance helps save labor for frequent roll material transportation.
- Roller material is listed as rubber, with PU, galvanized steel, and stainless steel as optional materials.
Applications
The round roll lifter can be used for packaging rolls, film rolls, textile rolls, paper rolls, and similar cylindrical materials. It is useful for moving roll materials between storage, production, cutting, and loading positions.
Model Specifications
| Specification | PF4120R | PF4150R |
|---|---|---|
| Rated load capacity | 400 kg | Confirm before quotation |
| Roller lifting height | 1200 mm | 1500 mm |
| Minimum roller lowering height | 180 mm | 180 mm |
| Roller dimension | 76 x 550 mm | 76 x 550 mm |
| Roller center distance | 180 mm | 180 mm |
| Applicable coil diameter | 200-600 mm | 200-600 mm |
| Roller material | Rubber; PU, galvanized steel, stainless steel optional | Rubber; PU, galvanized steel, stainless steel optional |
| Leg height | 80 mm | 80 mm |
| Overall dimension (L x W) | 780 x 630 mm | 780 x 630 mm |
| Overall height | 1420 mm | 1720 mm |
| Foot pump strokes for full lift | 45 | 58 |
| Net weight | 78 kg | 85 kg |
Buyer Notes
The source catalog table is visually unclear for one rated-load value, so final rated load should be confirmed before quotation. Buyers should provide roll diameter, roll width, roll weight, core type, handling frequency, and whether manual hydraulic or semi-electric lifting is preferred.
FAQ
What materials can the round roll lifter handle?
It is intended for roll and coil materials such as film, textile, paper, and similar cylindrical goods, subject to size and weight confirmation.
What is the lifting height range?
The catalog lists 1200 mm lifting height for PF4120R and 1500 mm for PF4150R.
Is a semi-electric model available?
Yes. The catalog describes a semi-electric version with lithium battery control box and electric button lifting with hydraulic assistance.
Inquiry CTA
Need a round roll lifter for roll material handling? Send roll diameter, roll width, loaded roll weight, required lifting height, and handling frequency so EASY LIFT can recommend the right configuration.
Buy Round Roll Lifter from EASY LIFT
round roll lifter buyers usually compare load capacity, working height, compatible drum or load size, operating space, wheel type, and optional configurations before requesting a quotation. This Round Roll Lifter PF4120R/PF4150R draft gives purchasing teams a clear starting point for model selection and supplier communication.
Round Roll Lifter Selection Checklist
- Confirm the required load capacity and maximum working height.
- Confirm the handled object size, such as drum size, roll diameter, fork width, platform size, or boom reach.
- Check whether the job needs manual hydraulic, semi-electric, or all-electric operation.
- Review aisle width, floor condition, turning radius, truck loading height, and storage space.
- Send application photos before quotation if the handled load is non-standard.
